Vertical Turbine Pumps







Process Pump and Seal is your local supplier of Vertical Turbine Pumps. We have been your local solution provider since the early 1980's and have a lot of experience with Vertical Turbine applications and helping you to find the right solution for your process. We provide Vertical Turbine Pumps from the manufacturers below (click the logo or the links below to learn more ! ):



American-Marsh Pumps                                                Worthington Pumps



Featured Product: American Marsh 480 Series Vertical Turbine Pump

Vertical turbine pumps are used in a variety of commercial, industrial, mining and municipal applications. Vertical turbine pumps are available in short set, deep set, submersible, mixed flow and propeller designs. These vertical turbines feature vitreous enamel-coated bowl assemblies, extra heavy-duty casings, high-efficiency enclosed or semi-open impellers, enclosed lineshaft assemblies and optional metallurgies.

Performance Specs

Capacities to: 30,000+ GPM (6,813+ m^3/hr)

Heads to: 2500+ Feet (762 m)

Temperatures to: 400 F (204 C)

Speed ranges: 900 to 3600 RPM

Features and Benefits

Heavy-duty Cast Iron/Bronze fitted bowls standard.

All bowl assemblies are flanged for ease in assembly and disassembly.

Bowls from 4″ through 20″ have an internal vitreous enamel porcelain lining and an external o-ring for drypit applications.

Heavy-duty discharge cases with dual bearings on bowl assemblies through 16″.

Optional metallurgy available including 316 stainless steel, Cd4MCu, and other duplex alloy stainless steels.

“CR” models feature casted integral abrasion webs that minimize the erosion action of entrained abrasives due to the vortex action and the rotation of the liquid between the individual pump stages.

“CR” models also feature suction and discharge bearings with a minimum of 5 inches in length which allows for more shaft support in the bowl assembly.

Special automotive-duty options with separate thrust stand for use where special motor options are required.

Cast iron or fabricated steel discharge heads.



Markets

  • Aerospace
  • Agriculture and Irrigation
  • Building Trades
  • Chemical
  • Food and Beverage
  • General Industry
  • Marine
  • Mining and Aggregate
  • OEM
  • Power Generation
  • Petrochemical
  • Pharmaceutical
  • Pulp & Paper
  • Semiconductor
  • Water and Wastewater
